Wheels, everything you need to know! From wheel size to load rating, it’s all here.
Already know your stuff? See some of our FAVOURITE BRANDS.
If you prefer to shop by vehicle type, we’ve got your favourite wheels to suit the VW T5 & T6, the VW Caddy, and the increasingly popular Ford Transit Custom & Connect platforms.
Download a PDF version of this blog here
If you’re looking to buy a new set of wheels (with intentions of improving appearance, comfort, or performance) you will need a set that fits your van correctly according to particular specifications.
You might be asking…
How do I choose the right wheels for my needs?
What’s PCD?
What offset should I be running and how do I calculate it?
What size of alloys will work best with my suspension setup?
What tyres do I need for my wheels?
Our wheel-dedicated blog post will give you everything you need as a van owner to make an educated decision on the most suitable (practically & aesthetically) wheels for your build. Here you’ll find the pros & cons of wheel size & width, the tricky-to-grasp offset debate, PCD, and, most importantly, load ratings attached to wheels & tyres alike.
- 275 WIDTH The width of the tyre measured in millimetres. This is largely determined by the actual rim width & can be increased or decreased to achieve perfect tyre fitments.
- 40 PROFILE Tyre profile is, effectively, the depth of the tyre wall. The 40 refers to the ratio of tyre wall to tyre width. Therefore, our tyre above has a tyre wall 40% (or 0.4) the depth of 275mm. This gives us a tyre profile of roughly 110mm.
- R20 DIAMETER This is the most self-explanatory part of the tyre wall. The 20 simply refers to the actual rim diameter this tyre is designed to fit. Once again, this is measured in inches.
- 106 LOAD Tyre load ratings are usually displayed as 2 or 3-digit numbers. These are as (if not more) important than your wheel’s load rating. These numbers correspond to load ratings in KG per tyre.
The first question you should be asking yourself might be…
What am I using my van for?
Answering this question may be able to help you decide on whether you need alloy wheels or steels.
Wheel size is perhaps the most deterministic factor when deciding on a set. When browsing our wheels, the two dimensions to take notice of are rim diameter (measured in inches) and rim width (also measured in inches).
In terms of diametre, bigger is usually better. Well, not too big. We, along with many other camper enthusiasts, have found 20” to be the sweet spot. That being said, popular sizes range from 16” to 20” depending on the application.
You’ll see this displayed most frequently as 20×8.5 for example. The ‘20’ refers to the diameter of the wheel in inches.
Width is a slightly more important factor than the previously mentioned diametre. This measurement largely determines how the wheel behaves on the road, what size tyres you buy, and the overall rolling resistance of the wheels.
Manufacturers typically don’t fit wheels any wider than 7J. We’ll come back to that ‘J’ later. From a manufacturer’s point of view, 7J is more than enough to achieve the desired levels of grip, comfort, and support the vehicle requires.
However, we, as van owners, want more. Much like diametre, bigger, in this case, wider, is better. We want 8J, 9J, and even up to 10J on some staggered width sets. Let’s take a look at how this is measured.
Again, you’ll find this represented most frequently as 20×8.5 or something similar. The ‘8.5’ refers to the width of the wheel in inches. As a stand-alone measurement, this will likely be displayed as 8.5J.
Put simply, PCD, or Pitch Circle Diameter, is the distance between the mounting holes on both your hub and wheels alike. This measurement, unlike size & width, is represented in millimetres. Some of our common PCDs at Vanstyle are 5×120, 5×108, and 5×112.
The first half of this measurement is simple. The 5 represents the number of holes per wheel. The second number represents the diameter of the pitch diameter circle. Simple as that. As long as you fit wheels with the same PCD as your current one (or according to your van’s spec) they’ll fit like OE wheels.
Offset, like many of the previous points, is an important factor when selecting the right wheels for your van. Put simply, offset (often seen as ET) determines how far in or out the face of your wheel sits in relation to the mounting surface. This is most commonly referred to as ‘poke’.
A lower positive offset (let’s say et32) gives more poke than a greater positive offset (et50). 18mm more to be precise.
That’s right, offset is also measured in millimetres.
Typically, the offset can be found stamped on the back of a spoke.
Each of the above wheels shares the same width, only the offsets vary. A positive offset places the mounting surface towards the face of the wheel in relation to the centre line, whilst a negative offset places the mounting surface further towards the rear of the wheel. ET0 is neutral positioning.
Measured in millimetres, the centre bore of a wheel is designed to fit snugly over the hub on your vehicle. OE wheels almost always match since they are specifically tailored to the vehicle in question. However, since aftermarket wheels aren’t vehicle specific, a spigot ring is likely going to be a necessary component to make the wheel fit that hub snugly.
This shouldn’t be a worry for you, however. We supply all wheels with the correct spigot rings (if required at all). One we see very often is 72.6mm – 65.1mm. Quite self-explanatory, this spigot ring adapts your 76.2mm wheel centre bore to fit the fixed 65.1mm hub diameter. Get it?
Always use spigots where required! They’re vital to a safe-fitting wheel.
Load ratings are arguably the most influential factor when selecting new wheels for a commercial vehicle. If they don’t meet your axle weights, they can’t be installed. Simple as that.
Don’t let this get you down, however. We, at Vanstyle, pride ourselves on offering a wide variety of hand-picked wheels from some of the world’s leading manufacturers, chosen specifically to be run on even the weightiest of campers. Rest assured, we’ve got you covered!
How might I check my vehicle’s axle weight?
Luckily, manufacturers make this really simple to check.
On most vans, this can be found on the vehicle plate located in a prominent area, typically in the door jamb or under the bonnet. Let’s take a VW for example, it should look a little something like this.
Here’s how a typical chassis plate might look on your van
The chassis plate contains vital information about your vehicle, including your chassis number as well as some important numbers around your van’s towing and carrying capabilities.
Let’s go through the numbers.
- 2800kg gives us the vehicle’s gross weight. In the Transporter world, this is where we get the T28 designation.
- 5200kg resembles the vehicle’s gross weight plus the maximum allowed trailer load.
- 01 – 1600kg gives us the vehicle’s front axle weight.
- 02 – 1550kg gives us the vehicle’s rear axle weight.
Disruption to Courier Services June 2023
Update Tuesday 27th June 2023 – 7pm
Thank you for your patience whilst we have been addressing our courier services issues further to the recent administration of Tuffnells.
On Thursday 22nd June we started moving our long-length parcels once again with our new courier partner, DX Freight.
Customers are now successfully receiving their goods and our warehouse team is now more or less caught up with the backlog which had been created whilst we have now long-length shipper services available.
By the end of this week, we anticipate all orders for in-stock long-length (or large volume items such as wheels & tyres), will be back on normal delivery terms of 2-3 working days.
For customers who have their items caught up in the Tuffnells network, we are working with the Tuffnells administrators to recover these parcels and we will be in contact with you as soon as possible.
Once, again we thank you for your patience and support during what has been a very hectic period, especially whilst we have also been a little short-staffed.
Thank you
Vanstyle
Update Tuesday 20th June 2023 – 7pm
We are pleased to report that our new courier services are now in operation.
Earlier today we have been able to go live with our courier services for long length parts with DX Freight.
Our team are now working through the back log of orders from the oldest through to the most recent.
We anticipate it is still going to take around another week to clear the back log and get up to date before we are in a position to have despatch times back to our normal levels.
The first batch of parcels have been loaded onto vehicles today and will begin passing through the network tomorrow. First deliveries will be with our customers from Thursday this week.
As mentioned in our previous updates, we will be working through the orders on a first in – first out basis.
We thank you for your continued patience and support.
Thank You
Vanstyle
Update Monday 19th June 2023 – 7pm
Further to the previous updates about our courier services, we were expecting to be able to bring news of the first batch of parcels having been re-labelled to be shipped with our new courier provider and for those parcels being out into the delivery network as of Tuesday 20th June.
Unfortunately, that is not yet the case and we are now awaiting updates from our new courier partner before 10am on Tuesday 20th June.
Therefore our current status remains as peer the update on Friday 16th June (below) where long length items are still on our warehouse floor awaiting collection, or in the case of orders which have been placed for long length items since Monday 12th June, they are sat as pending orders waiting to be processed through our system.
We have our full team of staff waiting to process these orders as a matter of priority as soon as we have the courier systems implemented and our team will be working as quickly as possible, as well as putting in additional hours, to get your parcels to you as quickly as possible.
If you need to contact us about your order, we would urge you to contact us by email via sales@vanstyle.co.uk
We apologise for the continued delay and thank you for your patience and understanding at this time.
Thank You
Vanstyle
Update Friday 16th June 2023 – 3pm
As reported earlier this week we have been facing disruption to our delivery services for long-length parcels further to the news of Tuffnells having gone into administration. On Monday 12th June.
Given the volume of parcels we move on a daily basis, the migration of our business to another courier provider raises many logistical challenges.
We have identified another courier partner who we can work with to move our freight, and are in the latter stages of ensuring the necessary measures are in place to be able to move parcels from our warehouse to their depots and out into their network for delivery to your door.
Rest assured this has been a matter of the highest priority for us throughout the week and we are committed to getting normal service resumed as quickly as possible.
We are now just working on the final details to get this implemented and we have been told we can expect to gain confirmation of the service by Monday 19th June.
So long as there are no further stumbling blocks, we will then be in a position to see the first of our large parcels moving into the new network from Tuesday 20th June with the first deliveries arriving with our customers by midweek.
Orders will be dealt with on a first in, first out basis and our warehouse team will be working extra hours to get these orders out as quickly as possible.
We will provide an update on the situation by lunchtime on Monday via our website.
For customers who have parcels that were already in transit at the time of Tuffnells administration, we are now in dialogue with the administrators to try and retrieve these parcels as quickly as possible.
We are unable to get at them immediately but we have vehicles on standby to collect them as soon as we are granted access and then these parcels will be forwarded on – unless you have already contacted us to cancel your order.
If you need to speak to us about your order, we would urge you to contact us by email via sales@vanstyle.co.uk.
Our phone lines remain very busy and we apologise for the delay in answering, but we are getting to you as quickly as possible and we do have new staff members due to join the team very soon to help us with the demand on the phones.
Our customer service team will have no further updates to this message at this time.
Any significant updates will be communicated this page and through our social media channels.
Once again, we would like to reiterate that smaller parcels remain unaffected by this disruption as they are already shipped with a different courier.
We thank you for your business and for your patience and hope you have a wonderful weekend and enjoy the sunshine.
Thank you
Vanstyle
Update Thursday 15th June 2023 – 3.30pm
Thank you for your continued patience whilst we deal with the issues around delivery of our long-length parcels.
As reported below, our services have been disrupted this week further to the announcement of Tuffnells going into administration.
The large majority of our orders continue to be processed as normal.
It is orders which contain long-length items (generally, sidebars, roofbars, front splitters, bonnet deflectors, awning rails and sunvisors) which are experiencing the delay.
Our team has been working incredibly hard to get the necessary transport logistics in place to move these items on and get them delivered to customers as quickly as possible.
We are moving closer to a solution and expect to have further news to share by 5pm on Friday 16th June.
A further update will be provided at that time (or before).
In the meantime, we thank you for your patience and please rest assured we are doing everything possible to get your goods on the move as quickly as we can.
Thank you
Vanstyle
Update 12th June 2023
On Monday 12th June 2023, Tuffnells, the express courier parcel service, went into administration which will have a short-term impact to some of our delivery services.
Tuffnells were our courier provider for deliveries of our longer-length parcels, so typically delivering products such as sidebars, roofbars, front splitters, and bonnet deflectors amongst others.
As a result, some orders placed between Wednesday the 7th June and Monday 12th June will experience delays whilst we deploy the alternative services.
We are now working as fast as possible to put services in place with alternative courier providers who can handle long-length parcels.
A small number of parcels that were already out in Tuffnells depots prior to the announcement are being recalled and we will be in contact with those customers affected as soon as possible.
Further updates will be made via this information page and our social media channels as things progress and we expect only a short-term delay to services.
We are already experiencing a high volume of calls to our sales office due to the high seasonal demand for goods, so if your enquiry is in relation to the delivery of parts, please be patient.
We will keep all customers informed of the service updates as soon as we have more information and our Senior Management team is working on the matter as the highest priority.
Orders for smaller items (typically packages below 1.4m in length) are unaffected by the news from Tuffnells as they are delivered by other courier services.
We apologise for any inconvenience this may cause and we thank you for your patience.
Vanstyle
Follow us on social for further updates:
A guide on why your van might benefit from premium poly bushings
What + Why Polyurethane Bushings.
A bushing is a cushion made of rubber, polyurethane, or other materials. They are installed in various places on your vehicle – control arms, sway bars, ball joints, tie rods, shock absorbers, strut mounts, and other suspension and steering components, as well as in engine and transmission mounts – with the purpose being to absorb road bumps, control movement in joints, reduce noise and vibration.
Bushes wear, and when that happens they begin to allow more movement which puts more stress on the connecting parts, which can allow metal-on-metal contact. Worn control arm bushings can cause your vehicle’s front alignment thus causing extra tire wear.
How do I know if my bushes need replacing?
In general, MOT detects bush play and movement during an inspection. However, you can do some visual checks. Most conventional rubber bushings consist of metal outer and inner parts that are glued in place.
This will loosen over time and disable the bushing. In addition, a visual inspection will allow you to see if the bushes are damaged or cracked. If the rubber is broken, it becomes unusable or noticeably softer. If you notice any of these symptoms, it may be something to do with your bushes – When turning or braking hard, you may feel a shimmy or hear a rattling noise from the front of the vehicle on rough roads. Drivers may also experience poor handling and loose steering. Failure of the rear suspension bushes can be difficult to detect as they do not affect the steering system and are less susceptible to cornering.
If you’re told by your MOT you need new bushes or you think your handling is being affected by old bushes, then it’s the perfect time to upgrade from your nasty standard rubber bushes to new poly bushings, a job you’ll only need to do once in most vehicles’ lifetimes.
Is it dangerous to drive with bad bushings?
Yes, driving with bad bushings is dangerous. Damaged bushings will result in poor steering and handling performance and loss of vehicle control. Also, don’t forget that it increases friction and can damage connected parts.
A lifetime upgrade for your van!
Poly bushings are great for vans as they are built to endure a lot of heavy loads or more rugged use which cars often won’t see, they are also a more durable and long-lasting aftermarket alternative. Throttle response and alignment are other areas where polyurethane shines and while it does transfer more NVH than OE rubber the performance benefits will outweigh the cost for most folks. Still, it is a matter of personal preference.
If you’re looking for better driving performance, direct steering, sharper, more responsive handling, and longer-lasting parts, Poly is your go-to choice when it comes to upgrading your bushings. Don’t worry if you’re taking your vehicle down the rugged path, poly bushings do not suffer, firstly because they are designed to suit the vehicle’s application. They also outperform in off-road conditions to the material’s ability to flex and rotate.
We’ve created a handy diagram below to help you identify the exact pieces you’ll need, or even to help you diagnose a bad bush if you’ve got an unwelcome knocking noise.
